Cameras

Max 32 analog + 128 IP/PoE cameras, total up to 160 cameras

Video/Audio Capture

2x 16 channels analog video capture card
Per channel resolution can be WD1/4CIF/2CIF/CIF/QCIF
32 channels H264 hardware compressed 960fps @NTSC or 800fps@PAL
32 channels mono audio compressed

CPU

Multiple cores 1 XEON or 2 XEON

GPU

Memory

16/32 GB

Storage

OS/AP
Media Video

2 x 120GB SSD in Raid-1 mirror
8 x3.5" or 2.5" SATA or SAS hot-swap HDD storages or
12 x3.5" or 2.5" SATA or SAS hot-swap HDD storages

Raid control

Hardware Raid 0, 1, 10(1E), 3, 5, 6, 30, 50, 60

DVD R/W drive

SATA interface (8 bays disk model)

USB

3.0x6
2.0x2

Audio

MIC-in/Speaker-out

COM

RS232

Ethernet IO

2x GbE
2x 10GbE (Optional) or 2x16G FC (Optional)

Display

DVI, HDMI, DP
Total 3 independent displays

OS

Win10 -64 or Windows server 2012R2-64

Application Software

VMS engine or DVR Recording/Playback/Live view
RemoteBrowser view/Mobile device clients
PSIM application software (Optional)
ANPR/LPR (Optional)
Face Recognition (Optional)

System Fan

4x 8cm

System Health status

IPMI port

Power Supply

Single 500W, AC 100V~240V, 50/60hZ
Redundant 800W power (optional), hot-swap, AC 100V~240V, 50/60hZ

LED

Power on/off, HDD, Ethernet

Certificate

FCC class A /CE, ROHS Compliant

Working Environment

Temperature

0~50℃

Indoor

Humidity

8% ~ 90%, non-condensing

Physical

Dimension

19" 2U rack
482(W)x 88(H)x 656(D) mm

Net Weight       20Kg

 Description

Order NO.

Basic

2U-8 bays DVR/NVR/VMS application software-1CPU

T504-H-32-8-1X

2U-8 bays DVR/NVR/VMS application software-2CPU

T504-H-32-8-2X

2U-12 bays DVR/NVR/VMS application software-1CPU

T504-H-32-12-1X

2U-12 bays DVR/NVR/VMS application software-2CPU

T504-H-32-12-2X

HDD 3.5" SATA storage

HDD 2.5" SATA storage

HDD 3.5" SAS storage

HDD 2.5" SAS storage

Redundant power

2x 10GbE RJ45 ports

2x 16Gb FC

PSIM application software

ANPR/LPR application software

Face Recognition application software
