NAS Shared Storage Solution

File ingest service solution
NAS
3U NAS
3U NAS
NAS throughput
Number of simultaneus streams count
Video shared storage equipment ideal for workgroups
10GbE x4 + 1GbE x4 to achieve max throughput
Flexible storage expansion
Optimize co-working with T601 live stream to file product series

Application

Video Editing multi-users professional
Security or IP Surveillance
Film, Post Production Facilities
Content Provider, Media Distribution
TV studio, VOD

Benefits

Concurrent workflow for video editing
Reliability
Cost-effective solution, return of investment quickly

Product Solution Features

Multiple users, share storages for video editing purpose
Low noise sound in operation
3U rack-mount chassis
24x7 365 days operation
Long-term supply

Technical Spec

CPU



Multi cores

Memory



32 GB

Storage

OS/AP
Media

512MB flash DOM
256GB SSD
Hot swap 16 x 3.5" SAS 12Gb/s disk storages
Raw Capacities: 32TB, 48TB, 64TB, 80TB or 96TB

Storage Expansion



Max 8 units, total 144 disk storages

UPS



(Optional)

Raid control


0,1,5,6,10,50,60

Ethernet IO


10GbE x4 + GbE x4
40GbE (Optional)

USB



3.0x4
2.0x4

OS



Embedded Linux

File Access Protocols



AFP, Samba (CIFS), NFS, FTP, FTPS, SFTP

LED



Status, 10 GbE, LAN, storage expansion port status

Alarm Buzzer



System warning

Power Supply



650 Watts Redundant (1+1) Hot-Swap 100~ 240V AC input, 50-60HZ

Power Consumption



Max DC@212 Watts

System Fan



4x8cm

Certificate



FCC class A /CE, ROHS Compliant

Working Environment

Temperature

0~40℃

Indoor

Humidity

5% ~ 95%, non-condensing



Physical

Dimension

443x 130x 530 mm

Net Weight 34Kg



*specification is subject to change without notice

System Order information

Product item

 Description

Order NO.

Basic

3U system, 16 x HDD

NAS-16-SAS-0000

Optional

Expansion unit



40GbE networking card



UPS
